MIL-COTS MI-RAM™
Ripple Attenuator Module


Description

The MI-RAM is designed for applications where extremely low noise outputs are required. When used with any Vicor MI-series DC-DC converter, the MI-RAM reduces both line frequency related ripple and switching noise to less than 10 mVp-p, DC to 20 MHz.
The combination of the MI-RAM with an MI-series converter provides the output noise performance of a linear supply at a power density in excess of 15 W/in³.

All of the features of the MI-series converter remain available while using the MI-RAM including output voltage trimming, OVP and OTP (MI-200™ only), current limiting, remote sense, and logic enable/disable.

Specifications
Input Voltages   5 – 50 VDC
Output Current   10 or 20 A
Efficiency   93 – 99%
Dimensions   2.28 x 2.40 x 0.50 in
57.9 x 61.0 x 12.7 mm






PDF Icon Data Sheet »

Find

Compatible Converters

The MIL-COTS MI-RAM – Ripple Attenuator Module – works in conjunction with a specific set of Vicor converters to deliver optimal efficiency, power and protection.

To easily view the appropriate converter components needed for the desired MIL-COTS MI-RAM, please use the PowerBench Solution Selector tool to locate compatible offerings.

Features & Benefits
  • Reduces output PARD to <10mV pp
  • Full attenuation up to 20 A load
  • Compatible with all MI-series units from 5-50 vdc output
Diagram

RAM with optional trimming circuit and recommended common–mode choke.



Click image to enlarge.



Documentation



Application Notes

PDFRAM Application Note »

PDFEMI Considerations for the RAM Module » (See page 28)

PDFSoldering Methods and Procedures for Vicor Power Modules »



Design Guide / Applications Manual

Download Entire Manual


PDFVI-200, VI-J00 Design Guide and Applications Manual »


Download Individual Chapters

PDF 1. Zero-Current Switching »

PDF 2. DC-DC Converter Pinouts »

PDF 3. Module Dos and Donts »

PDF 4. Overcurrent Protection »

PDF 5. Output Voltage Trimming »

PDF 6. Multiple Gate In Connections »

PDF 7. Applications Circuits / Converter Array Design Considerations »

PDF 8. Using Boosters and Parallel Arrays »

PDF 9. EMC Considerations »

PDF 10. Optional Output Filters »

PDF 11. Battery Charger (BatMod) »




Filter and Front-End Module Chapters

PDF 12. AC Input Module (AIM / MI-AIM) »

PDF 13. Harmonic Attenuator Module (HAM) »

PDF 14. Input Attenuator Module (IAM / MI-IAM) »

PDF 15. Ripple Attenuator Module (RAM / MI-RAM) »

PDF 16. Offline Front End »




Power System Chapters

PDF 17. DC Input Power System (ComPAC / MI-ComPAC Family) »

PDF 18. AC Input Power System (FlatPAC Family) »

PDF 19. AC Input Power System (PFC FlatPAC) »




General Chapters

PDF 20. Thermal and Module Mounting Considerations »

PDF 21. Thermal Curves »

PDF 22. Lead Free Pins (RoHS) »



PDF 23. Tin Lead Pins »

PDF 24. Module Packaging Options (SlimMod, FinMod, BusMod and MegaMod Families) »

PDF 25. Product Weights »

PDF 26. Glossary of Technical Terms »
