Wafer-level automated visual inspection systems ensure the highest quality and reliability of semiconductor ICs and enable manufacturers to continuously improve yields. These systems employ precision optics and analog circuitry to identify the smallest defects during wafer fabrication. As lithographic dimensions continue to shrink with advances in the latest process nodes, manufacturers require the highest defect sensitivities. This requirement places stress on the analog and mixed-signal circuitry in vision systems that require considerable noise filtering. As power needs increase, filters are becoming too large to be accommodated by these systems. A new approach to power delivery is required to keep pace with advances in semiconductor wafer fabrication.

Precision inspection equipment

The power delivery network

Automated vision system design engineers can reduce noise in sensitive wafer inspection systems starts with a reconsideration of the PDN. A critical first step is moving the system from an outdated 12V bus to a more power-efficient 48V bus to improve efficiency and thermal issues. However, to fully achieve wafer inspection requirements, it is necessary to employ a solution that is inherently low-noise. Vicor BCM fixed-ratio converters with sine amplitude conversion (SAC) topology mitigate noise and allow manufacturers to use less filtering. As an added bonus, the compact size and low profile simplifies thermal management that, in turn, simplifies the mechanical design of inspection systems.

Power Delivery Network for
BCM bus converters

BCM バスコンバータモジュール

入力電圧: 800 – 48V

出力電圧: 2.4 – 55.0V

出力電流: 最大150A

効率: 最大98%

22.0 x 16.5 x 6.7mm  他

DCM DC-DC converters

DCM DC-DCコンバータ

入力電圧: 9 – 420V

出力電圧: 3.3, 5, 12, 13.8, 15, 24, 28, 36, 48V

出力電力: 最大1300W

効率: 最大96%

24.8 x 22.8 x 7.2mm など

ZVS 降圧レギュレータ

入力電圧: 12V (8 – 18V), 24V (8 – 36V), 48V (30 – 60V)

出力電圧: 1 – 16V

出力電流: 最大22A

ピーク効率: 最大98%

10.0 x 10.0 x 2.5mm 他
