從派克峰到 Bonneville 鹽灘，Lightning 的速度超越內燃機機車
Lightning Motorcycle 設計的電動摩托車在各個領域都表現出色。瞭解 Vicor 電源模組如何支持下一代摩托車的詳情
Easing the transition to 48V power delivery
High power density
High efficiency
Easy thermal management
Parallel operation for multi‑kW arrays
High performance power modules optimized for 48V power delivery networks
Solutions for the entire power delivery network
The Vicor 48V ecosystem of high performance power modules provides complete power delivery networks to convert high voltage to a 48V bus, power downstream loads, and eases the transition with modules to power legacy 12V loads.
Enabling 12V/48V compatibility
Our regulated and fixed-ratio converters are easing the transition to inherent efficient 48V power delivery while alleviating the burden of re-designing systems that for decades have been optimized around 12V architectures.
Modules that convert 48V to 12V and 12V to 48V
High power 48V to 12V
非隔離 穩壓
輸入：40 – 60V
輸出：10 – 12.5V
功率：高達 2kW
峰值效率：96.5%
小巧至 36.7 x 17.3 x 5.2 毫米
Bidirectional 48V to 12V
非隔離固定比率
輸入：36 – 60V
輸出：7.2 – 15.3V
功率：高達 2400W
效率：超過 98%
小巧至 23 x 17 x 5.2 毫米
Compact 48V to 12V
非隔離穩壓
輸入：12V (8 – 18V), 24V (8 – 42V), 48V (30 – 60V)
輸出：2.2 – 16V
電流：高達 22A
峰值效率：98%
小巧至 10.0 x 10.0 x 2.56 毫米
Application examples
High performance computing
The Vicor NBM and DCM give data centers the flexibility to power legacy 12V boards when migrating to a 48V data center infrastructure. Utilizing the bidirectionality of the NBM allows for integrating the latest GPU into a legacy 12V infrastructure.
Automotive
The Vicor DCM and NBM enable the automobile industry to innovate with efficient 48V architectures while eliminating the gating factors of risk and timeframes reengineering the many legacy 12V systems being used in xEVs.
Battery testing
The Vicor DCM allows for an easier and quicker transition to a 48V architecture by providing conversion for legacy 12V buses powering the downstream cell monitor/balancing control units, delivering significant size, weight, and efficiency benefits.
Power System Designer
採用電源系統設計工具快速查找產品Watch demo video
