SOSA aligned power supplies

The Vicor SOSA-aligned power supply is a COTs power supply that is designed for 3U Open VPX systems that are developed to the SOSA standard. The module utilizes Vicor proprietary technology to enable high efficiency and power density for this highly rugged, conduction-cooled model.

Up to four power supplies can be paralleled to increase output power capability of +12V main and +3.3V auxiliary outputs with proprietary wireless current sharing. Need for conventional current‑share pins are eliminated. Current share accuracy is ±2A.

Vicor SOSA aligned power supply

SOSA

Filter Products

0 Products
0 Products
Part Number Nominal Input (V) Power (W) Form-Factor Conformal Coated Output Voltage Config. Add to cart / view details
SOS028H3U800C000
Part Number: SOS028H3U800C000 Nominal Input (V):
18 – 45
Power (W):
800
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U800D000
Part Number: SOS028H3U800D000 Nominal Input (V):
18 – 45
Power (W):
800
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U800C001
Part Number: SOS028H3U800C001 Nominal Input (V):
18 – 45
Power (W):
800
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U800D001
Part Number: SOS028H3U800D001 Nominal Input (V):
18 – 45
Power (W):
800
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Parallelable, VITA46 No-Key Guide Socket
View details
SOS028H3U151C000
Part Number: SOS028H3U151C000 Nominal Input (V):
10 – 45
Power (W):
150
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U151D000
Part Number: SOS028H3U151D000 Nominal Input (V):
10 – 45
Power (W):
150
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U151C001
Part Number: SOS028H3U151C001 Nominal Input (V):
10 – 45
Power (W):
150
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U151D001
Part Number: SOS028H3U151D001 Nominal Input (V):
10 – 45
Power (W):
150
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U300C000
Part Number: SOS028H3U300C000 Nominal Input (V):
18 – 45
Power (W):
300
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U300D000
Part Number: SOS028H3U300D000 Nominal Input (V):
18 – 45
Power (W):
300
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U300C001
Part Number: SOS028H3U300C001 Nominal Input (V):
18 – 45
Power (W):
300
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U300D001
Part Number: SOS028H3U300D001 Nominal Input (V):
18 – 45
Power (W):
300
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U301C000
Part Number: SOS028H3U301C000 Nominal Input (V):
10 – 45
Power (W):
300
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U301D000
Part Number: SOS028H3U301D000 Nominal Input (V):
10 – 45
Power (W):
300
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U301C001
Part Number: SOS028H3U301C001 Nominal Input (V):
10 – 45
Power (W):
300
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U301D001
Part Number: SOS028H3U301D001 Nominal Input (V):
10 – 45
Power (W):
300
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U451C000
Part Number: SOS028H3U451C000 Nominal Input (V):
10 – 45
Power (W):
450
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U451D000
Part Number: SOS028H3U451D000 Nominal Input (V):
10 – 45
Power (W):
450
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U451C001
Part Number: SOS028H3U451C001 Nominal Input (V):
10 – 45
Power (W):
450
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U451D001
Part Number: SOS028H3U451D001 Nominal Input (V):
10 – 45
Power (W):
450
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U600C000
Part Number: SOS028H3U600C000 Nominal Input (V):
18 – 45
Power (W):
600
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U600D000
Part Number: SOS028H3U600D000 Nominal Input (V):
18 – 45
Power (W):
600
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Parallelable, SOSA standard keying
View details
SOS028H3U600C001
Part Number: SOS028H3U600C001 Nominal Input (V):
18 – 45
Power (W):
600
Form-Factor:
3U
Conformal Coated:
Coated
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details
SOS028H3U600D001
Part Number: SOS028H3U600D001 Nominal Input (V):
18 – 45
Power (W):
600
Form-Factor:
3U
Conformal Coated:
Coated + AU-plated connector
Output Voltage Config.:
Programmable, VITA46 No-Key Guide Socket
View details

Power System Designer

Quick product searchWatch demo video

Input specifications

Min input: Minimum input:
Nom input: Nominal input:
Max input: Maximum input:

Output specifications

Output
Min output: Minimum output:
Nom output: Nominal output:
Max output: Maximum output:
Vicor Power System Designer

Features and Benefits

Features and benefits

Scalable OpenVPX compliant form-factor

Scalable OpenVPX compliant form-factor

Overcurrent, overvoltage and overtemperature protections

Overcurrent, overvoltage & overtemperature protections

Military standard compliance to MIL‑STD 704F, 461F, 810G, 1275D

Military standard compliance to MIL‑STD 704F, 461F, 810G, 1275D

High Reliability Modular Design

High Reliability Modular Design
