MIL-COTS DCM™ DC-DC Converter Module

Family Overview Select a Product

Rugged high power converters for 28V and 270V line inputs

The DCM is an isolated, regulated DC-DC converter, operating from an unregulated, wide range input to generate an isolated output. With its high frequency zero voltage switching (ZVS) topology, the DCM converter delivers high efficiency across its specified input line range. Modular DCM converters used independently or with downstream point of load (PoL) products support efficient power distribution, providing superior power system performance and connectivity from a variety of unregulated power sources to the point of load. The DCM VIA module provides a higher level of functionality with integrated EMI filtering, tight output voltage regulation and a secondary-referenced PM Bus control interface.

Features and Benefits

Features and benefits

Up to 500W, 17.86A continuous

Up to 1300W, 46.4A continuous

Up to 96% peak efficiency

Up to 96% peak efficiency

Power density

Up to 1,032W/in3 power density

OV, OC, UV, short circuit and thermal protection

OV, OC, UV, short circuit and thermal protection

Select a DCM

            0 Products
            Image Input (V) Output (V) Power (W) Package Optimized for Add to cart / view details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            3.3 (2.97 - 3.63)
            		 Power (W):
            120.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            3.3 (2.97 - 3.63)
            		 Power (W):
            120.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            5.0 (4.0 - 5.5)
            		 Power (W):
            180.0
            		 Package:
            3414 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            5.0 (4.0 - 5.5)
            		 Power (W):
            180.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            5.0 (4.0 - 5.5)
            		 Power (W):
            180.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            320.0
            		 Package:
            3414 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            320.0
            		 Package:
            3414 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            24.0 (14.4 - 26.4)
            		 Power (W):
            320.0
            		 Package:
            3414 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            24.0 (14.4 - 26.4)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            24.0 (14.4 - 26.4)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            28.0 (16.8 - 30.8)
            		 Power (W):
            320.0
            		 Package:
            3414 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            28.0 (22.0 - 30.8)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            28.0 (22.0 - 30.8)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            48.0 (28.8 - 52.8)
            		 Power (W):
            320.0
            		 Package:
            3414 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            48.0 (28.8 - 52.8)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            28.0 (16.0 - 50.0)
            		 Output (V):
            48.0 (28.8 - 52.8)
            		 Power (W):
            320.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            3.3 (2.97 - 3.63)
            		 Power (W):
            80.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            3.3 (2.97 - 3.63)
            		 Power (W):
            80.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            5.0 (3.5 - 5.5)
            		 Power (W):
            80.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            5.0 (3.5 - 5.5)
            		 Power (W):
            80.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            60.0
            		 Package:
            2322 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            60.0
            		 Package:
            2322 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            24.0 (14.4 - 26.4)
            		 Power (W):
            60.0
            		 Package:
            2322 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            24.0 (14.4 - 26.4)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            28.0 (16.8 - 30.8)
            		 Power (W):
            60.0
            		 Package:
            2322 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            28.0 (16.8 - 30.8)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            28.0 (16.8 - 30.8)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            48.0 (28.8 - 52.8)
            		 Power (W):
            60.0
            		 Package:
            2322 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            48.0 (28.8 - 52.8)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            30.0 (9.0 - 50.0)
            		 Output (V):
            48.0 (28.8 - 52.8)
            		 Power (W):
            160.0
            		 Package:
            3623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            3.3 (2.97 - 3.63)
            		 Power (W):
            150.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            3.3 (2.97 - 3.63)
            		 Power (W):
            150.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            5.0 (4.0 - 5.5)
            		 Power (W):
            250.0
            		 Package:
            3714 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            5.0 (4.0 - 5.5)
            		 Power (W):
            250.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            5.0 (4.0 - 5.5)
            		 Power (W):
            250.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            500.0
            		 Package:
            3714 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            12.0 (7.2 - 13.2)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            500.0
            		 Package:
            3714 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            15.0 (9.0 - 16.5)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            24.0 (14.4 - 26.4)
            		 Power (W):
            500.0
            		 Package:
            3714 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            24.0 (14.4 - 26.4)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            24.0 (14.4 - 26.4)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            28.0 (16.8 - 30.8)
            		 Power (W):
            500.0
            		 Package:
            3714 VIA
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            28.0 (16.8 - 30.8)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            28.0 (16.8 - 30.8)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            28.0 (16.8 - 30.8)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            48.0 (28.8 - 52.8)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Standalone
            		 View details
            Input (V):
            270.0 (160.0 - 420.0)
            		 Output (V):
            48.0 (28.8 - 52.8)
            		 Power (W):
            500.0
            		 Package:
            4623 ChiP
            		 Optimized for:
            Array
            		 View details
            Input (V):
            270.0 (180.0 - 400.0)
            		 Output (V):
            28.0 (22.0 - 36.0)
            		 Power (W):
            1300.0
            		 Package:
            5614 VIA
            		 Optimized for:
            Array
            		 View details

            Power System Designer

            Quick product search Watch demo video

            Input specifications

            Min input: Minimum input:
            Nom input: Nominal input:
            Max input: Maximum input:

            Output specifications

            Output
            Min output: Minimum output:
            Nom output: Nominal output:
            Max output: Maximum output:
            Vicor Power System Designer

            Resources

            Resources for the design engineer

            • Through-Hole Product Outline Drawing
              PDF DXF
            • Through-Hole Product Outline Drawing
              PDF DXF
            • 2322 ChiP Through-Hole Product 3-D Model Drawing
              IGS   STP
            • 3623 ChiP Through-Hole Product 3-D Model Drawing
              IGS   STP
            • 4623 ChiP Through-Hole Product 3-D Model Drawing
              IGS   STP
            • 3414 VIA DCM Chassis Mount with Comm Outline Drawing
              IGS   STP
            • 3414 VIA DCM Through-Hole Short Pin with Comm Outline Drawing
              IGS   STP
            • 3414 VIA DCM Through-Hole Long Pin with Comm Outline Drawing
              IGS   STP
            • 3714 VIA DCM Chassis Mount with Comm Outline Drawing
              IGS   STP
            • 3714 VIA DCM Through-Hole Short Pin with Comm Outline Drawing
              IGS   STP
            • 3714 VIA DCM Through-Hole Long Pin with Comm Outline Drawing
              IGS   STP
            • 5614 VIA DCM Chassis Mount with Comm Outline Drawing
              IGS   STP
            • 5614 VIA DCM Through-Hole Short Pin with Comm Outline Drawing
              IGS   STP
            • 5614 VIA DCM Through-Hole Long Pin with Comm Outline Drawing
              IGS   STP

            Promo Component

            Get more documents, videos and case studies in the resource library for engineers
            Go to the Library

            Related Products

            Related Products

            Contact Form

            Get in touch with Vicor

            Thank you for contacting us

            You should receive a reply to your request within one business day.
